Offsite Construction and Prefabrication in Civil Engineering

By Akio
Share on LinkedInTweet about this on TwitterShare on FacebookShare on Google+

clicktotweetClick to Tweet: “Offsite Construction & Prefabrication in
#CivilEngineering | @3DSAEC @Dassault3DS”

Prefabrication is the designing and manufacturing of assemblies under factory conditions, then transporting them to—and assembling them on—a construction site. The technique is most widely used for concrete and steel sections in structures where a particular part or form is repeated many times.

In civil engineering, prefabrication plays a key role in the construction of bridges, roads, tunnels, and more. Prefabrication can be used for:

  • cantilevered decks of elevated bridges in highway projects
  • parapets of expressways and road curbs
  • precast girder units and beams for elevated roadways, tracks, viaducts, and pedestrian footbridges
  • decks for long span bridges
  • tunnel linings, especially for tunnels formed by tunnel boring machine
  • sea walls
  • railway platforms
  • noise barrier panels
  • overhanging ducts and service channels for underground facilities
  • storm water discharge culverts

… and many other elements of a civil design project.

Contributing Factors to the Prefabrication Trend in Civil Engineering

The main reason for prefabrication construction is to reduce the overall construction time on a project. This time savings can yield significant budget savings.

Prefabrication allows for work to be conducted simultaneously onsite and offsite, as well as helping with better coordination among the project team.

Less onsite staging, such as scaffolding, is needed. Weather does not impact construction. Prefabrication can also reduce onsite resources, such as labor and equipment, and minimize waste. Factory conditions offer quality control checks on each piece produced.

Prefabricated concrete, for example, can avoid the imperfections frequently found in concrete poured onsite. The lack of exposure to the elements, and the ability to fabricate in factory conditions rather than on ladders or from scaffolding also improves quality.

Examples of Civil Design Projects Using Prefabrication

clicktotweetClick to Tweet: “Examples of #CivilDesign Projects
using #Prefab | @3DSAEC @Dassault3DS”

Goethals Bridge

Goethals Bridge Prefabrication

Goethals Bridge. SOURCE.

The new replacement Goethals Bridge, linking Elizabeth, New Jersey, to Staten Island in New York City, is currently under construction and has a cable-stayed design. The replacement bridge will be located directly south of the 88-year-old existing Goethals Bridge.

The design of the $1.5 billion project was led by Kiewit-Weeks-Massman. Prefabricated steel will compose two spans, one eastbound and one westbound, to measure 1,635 feet. The project team is constructing 36 precast concrete structural support columns for the foundation—18 each for the eastbound and westbound roadways—consisting of prefabricated steel rebar shafts.

Prefabricated anchor boxes will be installed at the top section of the bridge’s eight towers. The new bridge is scheduled to open in 2017 on time.

Crossrail

Crossrail Prefabrication

Crossrail. SOURCE

The Crossrail railway project in London is Europe’s biggest underground construction project.

Twenty-six miles of twin-bore tunnels have been built for the addition of 10 stations and linking to 30 existing stations. Eight tunneling machines bored the 6.2 diameter rail tunnels, 40 meters under London.

Over 200,000 prefabricated concrete segments line the tunnels. Seven segments and a keystone will be used to make up tunnel rings, locked together to build a concrete tube reinforced with steel fibers. Each segment weighs 3,000 kilograms and each keystone weighs 1,000 kilograms. Crossrail construction is being delivered on time and within budget.

Panama Canal Expansion

Panama Canal Prefabrication

Panama Canal. SOURCE.

The Panama Canal expansion project adds a new lane to the existing two lanes to allow for passage of large vessels, such as container ships, bulk carriers, and tankers. Work began in 2014 and is expected to be complete in May 2016 at a cost of over $5 billion. The new lane will have two locks chambers, one on the Pacific side and one on the Atlantic side.

Installation of 16 prefabricated rolling steel lock gates was completed last year. They were manufactured in Italy, then shipped, tugged, and “rolled” to the site.

clicktotweetClick to Tweet: 16 lock gates were #prefab’ed in Italy then shipped,
tugged & rolled to @thepanamacanal | @Dassault3DS #Civildesign

When complete, ships will enter through two-pair of buoyant gates, which are 7-feet-thick, weigh up to 3,200 tons, and are up to 82-feet high. In addition, 46 prefabricated steel lock walls were put into place to hold water in the lock chambers that range from 45- to 55-feet thick at the base to 8 feet at the top.

West Kowloon Terminus Station North

West Kowloon Terminus. SOURCE.

West Kowloon Terminus. SOURCE.

The West Kowloon Terminus Station North is the largest civil contract awarded for the Hong Kong section of the Guangzhou-Shenzhen-Hong Kong Express Rail Link.

Located in Kowloon, the terminus will serve as Hong Kong’s international gateway to China. Engineering firm BuroHappold designed a curved, steel, and glass roof to accommodate a large central space to provide natural light and views of Hong Kong Island. The free-form roof will be made up 7,000 tons of prefabricated steel trusses weighing up to 40 tons each.

Doubly-curved trusses, triangular in cross-section, will form three long curved lattice trusses. These will be supported by prefabricated curved steel columns up to 50 meters in height. A concrete roof beam for the steel roof will be comprised of six concrete cantilevering beams, with eight concrete sections spanning between each beam.

clicktotweetClick to Tweet: “Offsite Construction & Prefabrication in
#CivilEngineering | @3DSAEC @Dassault3DS”

Related Resources

INDUSTRY SOLUTION EXPERIENCE: Civil Design for Fabrication

WHITEPAPER: Civil Design Innovation – Innovative Industrialization Methodology Achieves Breakthrough in Civil Design

WEBINAR: Extended Demo of Civil Design Industry Process Experience




Spotlight on CadMakers Virtual Construction

By Akio
Share on LinkedInTweet about this on TwitterShare on FacebookShare on Google+

clicktotweetClick to Tweet: Spotlight on @CadMakersCo |
#VirtualConstruction #AEC @3DSAEC

AEC Industry Solution Experiences on the 3DEXPERIENCE platform enables designers to view 18 floors of MEP elements at fabrication LOD 400 on what will be the world’s tallest wood building.

SMARTER BUILDING

CadMakers Virtual Construction understands that the cost to construct a building is a small percent of the total lifecycle cost the structure. The company thinks it’s just as important to efficiently plan for maintenance as it is to build a structure, which is why CadMakers takes a holistic view of the AEC process.

clicktotweetClick to Tweet: Planning for maintenance
is just as important as building a structure

“People have thought that you can’t use manufacturing best practices in AEC because everything is different in our industry,” explained Javier Glatt, co-founder and CEO of CadMakers, a service company built to streamline the AEC industry and has executed 35 projects worth over US$3 billion in construction value since early 2014. “But new technologies, such as the 3DEXPERIENCE® platform, are enabling this industry to automate processes and create a lot of value.”

CadMakers employs Dassault Systèmes’ cloud-based 3DEXPERIENCE platform to promote collaboration throughout the AEC value chain and enable smarter building.

CadMakers uses AEC Industry Solution Experiences to assist in three key areas: identifying conflicts in building systems design before construction begins; coordinating on-site sequencing during the construction process, and ultimately, providing a detailed map for maintenance services during the building’s lifecycle.

“Virtual design and construction is the idea of taking all of the building systems — architectural, structural, mechanical, electrical and plumbing — and map them virtually,” Glatt explained. “That enables us to identify and resolve problems in advance of live construction.”

“The future of the construction industry is to effectively manufacture buildings as opposed to stick build on site,” Glatt added. “Increasingly, building will be done in a factory floor in a safer and climate-controlled environment only to be assembled on site, similar to how the airplane manufacturing industry has evolved.”

Architectural, structural and MEP coordination of a complex project using IFC and the 3DEXPERIENCE platform.

VIRTUALLY BUILD IN 3D

Opposed to the typical multi-page set of 2D drawings used by construction project managers, CadMakers shows its clients highly detailed, accurate 3D models early in the building process, which increases efficiency.

“The difference between working in 3D and 2D is powerful,” Glatt said. “Roughly 30% of the problems or risks we identify in a given project result entirely from the fact that we’re able to view the building and its systems in an integrated, 3D model.”

The difference becomes clear to CadMakers’ clients when they get to share the 3D building model created with the 3DEXPERIENCE platform.

“The 2D architectural drawing is one page, the structural drawing is another, and various building systems are on subsequent pages,” said Ryan Yee, project modeling designer, CadMakers. “But when we use the CATIA application, the 3D building model is right in front of you and that’s where the value is. You can be very clear: ‘here are the ducts, here is the wall, here is the ceiling, and this is why your duct is below the ceiling.’”

“The recent increase of project teams using Building Information Modeling has created new silos, with an uneven adoption of technology amongst teams, adding complexity to traditional project procurement methods,” Glatt said.

“Integrated project delivery methods will become more important to drive efficiencies on complex projects. In this new world, prefabrication and manufacturing processes will be critical to maximizing value to owners.”

“New technologies, such as the 3DEXPERIENCE platform, are enabling the AEC industry to automate processes and create a lot of value.”
— Javier Glatt, Co-founder and CEO, CadMakers

clicktotweetClick to Tweet: “New tech is enabling #AEC to automate
processes & create a lot of value.”

SHARING THE 3DEXPERIENCE

The freedom to share the 3D building model throughout a project’s team is a key reason that CadMakers chose the 3DEXPERIENCE platform.

In work for UBC Properties Trust, who optimizes the University of British Columbia’s land assets, CadMakers uses a 3D model to serve in a quality assurance/quality control capacity.

Glatt says the project team at UBC likes to get everyone — the project’s architect, engineers and various subcontractors — in a room together to view the model and crowdsource solutions to potential problems.

It doesn’t take long for everyone to drill down to their own concerns. “An electrician had us zero-in on one area of the model. ‘OK,’ he says, ‘how much clearance do I have to get through this shaft? If there’s a duct there, how am I going to get my conduit in there?’ We were solving those problems in real time,” Glatt said.

The real value in such reviews, he adds, is combining the hands-on expertise and experience of construction industry veterans with the visualization provided by the 3DEXPERIENCE model.

A veteran electrician or plumber doesn’t need to learn to manipulate the model, however.

“We’ll do the heavy lifting, but we need the construction veterans to be the brains behind it all,” Glatt said. “We ask him, ‘how close can we get these pipes together? What about hangers? Flanges? Valves? How are you going to actually install this and in what order?’ So we get that veteran expertise and we’re capturing it to shape the model in real time.”

RESOLVING THE COMPLEX CONSTRUCTION PROCESS

With Optimized Planning, including the DELMIA application, users move beyond a static model and show clients how the building components will be assembled together.

“When you build the 3D model, you have all of the parts and pieces there, every nut and bolt, but you may not think through the complexity of construction,” Yee explained. “Using the DELMIA application within Optimized Planning, you can see piece-by-piece, assembly-by-assembly, the sequence and processes of construction.”

That has real benefits on a complex job site. It provides informed decisions about when materials and assemblies are delivered to the job site, and where they are placed on the site in relation to the crane, as it can only pick up so many items in a day.

Using the 3DEXPERIENCE platform to connect the value chain through all of the suppliers and subcontractors, the general contractor can optimize deliveries and minimize bottlenecks on the job site.

“Where you put the crane is very important, as it dictates process and flow,” Yee said. “With the DELMIA application within Optimized Planning, you can visualize which tasks need to be prioritized, and which can be scheduled in conjunction with others. That improves efficiency to shorten the construction timeline.”

NEW INSIGHT SOLVES PROBLEMS OFF-SITE

Within the 3DEXPERIENCE platform, the CATIA application enables users to design piping, tubing and HVAC systems from concept through detailed manufacturing.

Moreover, users can build intelligence regarding the new system into the 3D model.

“Let’s say you add an elbow to the HVAC system. That changes the friction in the system, which in turn changes the fan specs,” Yee explained. “In CATIA, when you add elbows you can link them to the standards of your entire HVAC model, and it will identify what fans or valves you’ll need when you change the design.”

A new piping interface and platform lets users place specific elements in defined locations.

Users select the equipment, supports, hangers and more; then CATIA creates the route.

“You know the pipe is going from point A to point B, so why should you do all the leg work to route it when the software will do it for you — and probably do it better?” Yee asked.

The bottom line, he continues, is that CATIA enables users to identify issues in a plumbing or HVAC design and resolve them before the system gets to the worksite.

clicktotweetClick to Tweet: “CATIA enables users to resolve design issues
before the system gets to the worksite” @CadMakersCo

HOLDING ONTO THE KNOWLEDGE

Glatt believes the 3DEXPERIENCE platform has a definitive competitive advantage: its data-driven, model-based architecture delivered by the ENOVIA application within Optimized Construction, seamlessly connect business processes.

This architecture, he argues, enables users to leverage the 3D model in new ways.

One prime example is the long-term facility maintenance and management that occurs long after architects, engineers and construction crews leave the site.

“When the project is turned over to operations and maintenance staff, are they going to have the expertise and know-how to manage new wastewater systems and complex mechanical systems in a building?” Glatt asked rhetorically. “We can design new technologies into buildings, but can we operate them for the next 50 years? That’s where the ENOVIA application in the 3DEXPERIENCE platform can be extremely powerful.”

The metadata behind a 3DEXPERIENCE model, Glatt explains, includes every pump, filter and substructure in an easily searchable form.

It can even include warranties and maintenance schedules for all of the building systems.

As a result, high quality building maintenance and operation can be built into the project from the start, rather than relying exclusively on the skills of a maintenance staff that learns a building’s idiosyncrasies over time.

Sooner or later, members of that maintenance staff will retire, so their experience and specific building knowledge will be lost; but content in the data-driven, model-based ENOVIA architecture will remain forever.

SOLVING COMPLEX PROBLEMS WITH TECHNOLOGY

Combining their technological expertise with the 3DEXPERIENCE platform to power its virtual design and construction business has been the crux of CadMakers’ success.

“We believe in solving problems using technology, and we believe the 3DEXPERIENCE platform may be the most powerful software available to our industry today,” Glatt said. “It’s an excellent match for very large, complex projects. You don’t just have an architectural model, or a single building system. You have every mechanical, electrical and plumbing system right in front of you.

“In the 3DEXPERIENCE platform, Dassault Systèmes has created an amazing technical solution. It’s up to us to leverage its capabilities to solve real problems on the front lines of architecture, engineering and construction for our customers.”

clicktotweetClick to Tweet: Spotlight on @CadMakersCo
| #VirtualConstruction #AEC @3DSAEC

RELATED RESOURCES

WHITEPAPER | End-To-End Collaboration Enabled by BIM Level 3: An Architecture, Engineering & Construction Industry Solution Based on Manufacturing Best Practices

Collaborative & Industrialized Construction with Dassault Systèmes
